TP321 321H ERW Ss Tubin soldado de aço inoxidável para a engenharia da água de esgoto
Product Details
| Material: | TP304 TP304L TP316 TP316L | Terminação: | Solução recozida & conservada |
|---|---|---|---|
| Aplicação: | cambista do boiler&heat, energia, petroquímico, mineração, alimento, papel, gás e indústria fluida | forma: | Tubo soldado |
| OD: | 15.9mm a 406.4mm | PESO: | 0.89mm a 5mm |
| Destacar |
tubulação 316l de aço inoxidável,tubo de aço inoxidável frente e verso |
||
Product Description
Tubo soldado de aço inoxidável de TP321/321H ERW para a engenharia da água de esgoto
Padrão de ASTM A249:
| Tamanho OD | Parede nominal | Diâmetro externo | Comprimento | Parede |
| 1/2” (12,7) | 0,065" (1,65)/0,049" (1,25) | +/--0.005 (0,13) | +1/8" (3,18) - 0 | +/--10,0% |
| 3/4" (19,1) | 0,065" (1,65)/0,049" (1,25) | +/--0.005 (0,13) | +1/8" (3,18) - 0 | +/--10,0% |
| 1" (25,4) | 0,065" (1,65)/0,049" (1,25) | +/--0.005 (0,13) | +1/8" (3,18) - 0 | +/--10,0% |
| 1-1/2” (38,1) | 0,065" (1,65)/0,049" (1,25) | +/--0.008” (0,20) | +1/8" (3,18) - 0 | +/--10,0% |
| 2" (50,8) | 0,065" (1,65)/0,049" (1,25) | +/--0.008” (0,20) | +1/8" (3,18) - 0 | +/--10,0% |
| 2-1/2” (63,5) | 0,065" (1,65) | +/--0.010” (0,25) | +1/8" (3,18) - 0 | +/--10,0% |
| 3" (76,2) | 0,065" (1,65) | +/--0.010” (0,25) | +1/8" (3,18) - 0 | +/--10,0% |
| 4" (101,6) | 0,083" (2,11) | +/--0.015” (0,38) | +1/8" (3,18) - 0 | +/--10,0% |
| 6" (152,4) | 0,083" (2,11) | +/--0.030” (0,76) | +1" (25,4) - 0 | +/--10,0% |
| 6" (152,4) | 0,109" (2,77) | +/--0.030” (0,76) | +1" (25,4) - 0 | +/--10,0% |
| 8" (203,2) | 0,109" (2,77) | +0,061" (1,55) /-0,031" (0,79) | +1" (25,4) - 0 | +/--10,0% |
Categoria material:
| Padrão americano | TP304, TP304L, TP310S, TP316, TP316L, TP316Ti, TP321, TP347, 904L, S31803 etc. |
| Padrão europeu | 1,4301, 1,4306, 1,4845, 1,4401, 1,4404, 1,4571, 1,4541, 1,4550, 1,4539, 1,4462 etc. |
| Padrão alemão | X5CrNi18-10, X2CrNi19-11, X12CrNi25-21, X5CrNi17-12-2, X5CrNi17-12-3, X2CrNiMo18-14-3, X6CrNiTi18-10, X6CrNiTb18-10 etc. |
1 . OD (diâmetro exterior): 15.9mm a 406.4mm
2 . PESO (espessura de parede): 0.89mm a 5mm
3 . Comprimento: De acordo com a exigência de cliente
4 . Padrões: ASTM A312; ASTM A269; ASTM A789; Ect de ASTM A790
5 . Método do processo: ERW, EFW etc.
| pplication: | a) Para o transporte do líquido e do gás |
| b) Estrutura e fazer à máquina | |
| c) O permutador de calor conduz etc. | |
| Vantagens: | a) Revestimento da superfície do superior |
| b) Melhor propriedade mecânica | |
| c) Dimensão mais precisa | |
| d) Método perfeito da inspeção e equipamento da inspeção | |
| Artigo do preço: | CORRENTE DE RELÓGIO, CFR, CIF ou como a negociação |
| Pagamento: | T/T, LC ou como a negociação |
Product Highlights
Tubo soldado de aço inoxidável de TP321/321H ERW para a engenharia da água de esgoto Padrão de ASTM A249: Tamanho OD Parede nominal Diâmetro externo Comprimento Parede 1/2” (12,7) 0,065" (1,65)/0,049" (1,25) +/--0.005 (0,13) +1/8" (3,18) - 0 +/--10,0% 3/4" (19,1) 0,065" (1,65)/0,049" (1,25) +/--0...
